Description
Capstan Quick THG 1000W 12v
This product is Manufactured or Distributed by Quick . Capstan Quick THG 1000W 12v ,
Introducing the Capstan Quick THG 1000W 12V, an outstanding solution for easily retrieving tenders or other loads without the hassle of using a rope. This capstan boasts a sturdy anodised aluminium base and roller drum, ensuring both durability and reliability. It features an IP67 watertight motor, available in 1000W and 1500W models, while the 500W model is equipped with an IP66 watertight motor. Additionally, the unit comes with a complete control box and a polymer cover for enhanced protection.
Key Features:
- Strap roller designed for efficient load retrieval
- Anodised aluminium base and drum for increased durability
- IP67 watertight motor for 1000W and 1500W models; IP66 for the 500W model
- Anodised aluminium gearbox for dependable performance
- Supplied with a standard plastic cover for added protection
Please note that the strap, available in sizes of 48 mm x 7.5 m or 48 mm x 10 m, must be ordered separately. An ISO8846 version, which offers ignition protection, is available upon request.
Specifications:
| Model | THG500 | THG500 | THG1000 | THG1000 | THG1500 | THG1500 |
|---|---|---|---|---|---|---|
| Reference | QT554 | QT554 | QT154 | QT154 | QT154 | QT154 |
| Motor Power | 500 W | 500 W | 1000 W | 1000 W | 1500 W | 1500 W |
| Voltage | 12 V | 24 V | 12 V | 24 V | 12 V | 24 V |
| Max Pull | 1200 kg | 1200 kg | 1700 kg | 1700 kg | 2000 kg | 2000 kg |
| Max Working Load | 600 kg | 600 kg | 750 kg | 750 kg | 1000 kg | 1200 kg |
| Working Load | 200 kg | 200 kg | 300 kg | 350 kg | 400 kg | 500 kg |
| Current Absorption @ Working Load | 85 A | 50 A | 70 A | 40 A | 108 A | 66 A |
| Max Speed @ Working Load | 5.5 m/min | 5.8 m/min | 4.2 m/min | 4.8 m/min | 5.5 m/min | 6.8 m/min |
| Weight | 14 kg | 14 kg | 18.9 kg | 18.9 kg | 18.9 kg | 18.9 kg |
This detailed overview of the Quick THG Capstan provides you with all the essential information needed to make an informed decision. If you have any further questions or require assistance, please do not hesitate to contact us
