Windlass Quick Genius GP2 250W 12v Free-Fall

This product is Manufactured or Distributed by Quick . Windlass Quick Genius GP2 250W 12v Free-Fall ,

Introducing the Anchor Windlass Quick Genius GP2 1200, a robust and efficient 250W 12V free-fall rope and chain windlass designed for on-deck use. This model features a durable anodised aluminium casing, complemented by bronze and stainless steel traction components. It is equipped with a chain counter sensor and boasts an IP66 watertight motor, ensuring reliable performance in various marine conditions. The package includes a control box and handle for ease of operation.

The Genius GP2 Horizontal Windlass is suitable for boats ranging from 6 to 9 metres (20 to 30 feet) in length. Its aluminium casing is treated with a hard oxide coating for enhanced durability. The rope and chain gypsy is fitted with a chain counter sensor, and the windlass features a pressure arm for added functionality. Its compact and sturdy design allows it to fit into tight spaces without compromising power.

Key specifications include:

• Drum: No
• Motor Power: 250 W
• Input Voltage: 12 V
• Maximum Pull: 550 kg
• Maximum Working Load: 170 kg
• Working Load: 50 kg
• Chain Speed at Working Load: 25 m/min
• Current Absorption at Working Load: 35 A
• Deck Thickness: 20-40 mm
• Weight: 9 kg
• Gypsy Size: 6 mm

This windlass is an excellent choice for boat owners seeking a reliable and high-quality solution for anchoring needs
