Description

This water-resistant 692 series angular plug is ideal for use on board thanks to the glass fiber reinforced plastic housing. The 7-pin version is used, for example, to connect wind measurement devices.

Technical data:

• No. of poles: 7
• Connection cross-section max.: 1.5 mm²
• Type of connection: screw
• Cable outlet: 6-12 mm
• Contact surface: Ag
• Protection: IP67
• Housing material: PBT-gv
• Nominal current per contact: 10 A
• Nominal voltage: 50 V
• UL-94 flammability: non-flammable
